Four Roll Rubber Calender


Introduction:

1. The four roll Rubber Calender Machine is mostly used in oppression of rubber products and textile(like cotton, rayon, nylon etc. ). The precision Rubber Calender besides has the ordinary calender main spare part and the equipment, increased the guarantee rolling precision installment.

2. We have three-roll, four-roll and two-roll calender, should any of items be of interest to you, please contact me for further details.

3. Four Roll Rubber Calender Machine is according to certain form arrangement, under certain temperature, extends the rubber or the plastic suppression certain thickness and the superficial shape film.

Slide left & right to view full parameters

Parameter/Type XY-4I 630
XY-4L 630
XY-4Γ630		 XY-4Γ1120A XY-4Γ1400 XY-4Γ1500 XY-4Γ1730 XY-4Γ2130 XY-4Γ2430
Roll Diameter(mm) 230 360 400 450 610 710 810
Roll Working Length(mm) 630 900 1400 1500 1730 2130 2430
Roll Ratio 1:1:1:1 0.73:1:1:0.73 1:1.383:1.383:1 1:1.5:1.5:1 1:1.4:1.4:1
1:1.4:1.4:1.4		 1:1:1
1:1.48:1		 1:1.5:1.5:1
Middle Roll Speed(r/min) 2.1-21 2-20.1 3-26.3 2.5-25 8-50 8-50 2-20
Adjusting Nip Range(mm) 0-10 0-10 0-10 0-6 20 0-20 0.5-25
Min. Product Thickness(mm) 0.2 0.2 0.2 0.2 0.15 0.15 ±0.1
Calendering Product Width(mm) 100-500 500-920 1200 1250 1500 1900 2150
Motor power(KW) 15 55 75 110 160 185 280
Dimension(L×W×H)(mm) 5330×940×2350 6600×1620×2490 6500×1970×2740 6580×2460×2920 7010×4150×3730 9800×4260×5720
