Press Loop Machine


Qingdao Shun Cheong Machinery Co., Ltd is the professional manufacturer of various vulcanizing press and press machine. Our company has passed ISO9001:2008 Quality Management System Certification and our products have qualified with Sweden SGS Certificate, UKS Certificate and CE Certificate.

Semi-automatic rubber powder production line technological process

Waste tires - Ring Cutter - Strip Cutter - Block Cutter  - Press Loop Machine  - Rubber Crusher  - Oscillating Screen - Fiber Separator (rubber powder diameter 1.7mm ~ 0.55mm) - Fine rubber powder grinding machine - Powder (rubber powder diameter 0.55mm ~ 0.12mm).

The following is the technical parameters for press loop machine.

Slide left & right to view full parameters

Model YQJ-285
Diameter of Pressing Roller(mm) 285
Main Power(KW) 15
Front Roller Linear Speed(m/min) 15.5
Speed Ratio 1.1
Overall Size(Length*Width*Height)(mm) 1520*1150*1210
